BUILDING
SPECIFICATIONS
The
building – Description
The building
is composed of four floors and 16 apartments of various types, 2bedroom,
3bedroom and 4 bedroom apartments. The building will be consist of the basement
where the parking spaces, lifts, the stores and a private gym are located, the
ground floor with apartments and building entrance, the first floor with 5
apartments, the second with 4 apartments and the third floor with 3 apartments.
Structural
specifications
Building’s Energy Characteristics
All apartments have class A’ Energy Coefficient with low CO2 emissions,
environmentally friendly.
Frame
The frame of the building will be of reinforced concrete.
Walls
The masonry infills will be constructed of bricks and three coats of render
internally. Externally a thermal insulation system will be applied. The
exterior walls will be 250mm thick and the interior will be dry wall system
105mm thick.
Roofing - Waterproofing
Non reinforced concrete, 4mm asphalt membrane insulation, extruded polystyrene.
Non-reinforced concrete and cement based water insulation on the verandas and all
external floors.
Floorings
All internal conditioned spaces with underfloor heating will be covered with
100 mm screed on lightweight concrete screed for covering services.
Paint-work
Three coats of emulsion paint on interior walls in general. Three coats of
emulsion and spatula on interior ceilings. Sandex paint and spatula on
exterior ceilings. Oil paint or hummerite
paint on the metal
surfaces of railings. Oil paints in general will be applied in three coats
(primer, undercoat and finish).
External
works
General earthworks and concreting works for the shaping of exterior spaces.
Concrete walls on the ground floor as approved drawings. Construction of public
pavement and landscaping.
Plumbing
Water supply will be achieved with a pressurised plumbing system of pipes of a
minimum 15mm diameter, hot water return pump, sewage /drainage and drainage
gutters on the terrace for rainwater. Water tanks equivalent of 1 ½ tons
capacity for each apartment. Hot water supply system will be achieved via solar
collectors and electric element.
Mechanical
works
Water underfloor heating system with electric heat pump of high energy class
for each apartment. Supply
and Installation of air-conditioning units with VRV system, wall mounted on the
bedrooms and concealed on the kitchen, dining/living room. Mechanical
ventilation for interior lavatories/bathroom.
Electrical works
Each apartment will have photovoltaic system on the roof for renewable source
of energy to achieve the class A energy coefficient. Installation of electrical
parts of European manufacturer. At least 16 free plug sockets, 3 telephone
outlets and 3 television outlets to be included for the 2-bedroom apartments.
At least 21 free plug sockets, 4 telephone outlets and 4 television outlets to
be included for the 3-bedroom apartment. At least 24 free plug sockets, 6
telephone outlets and 6 television outlets to be included for the 4-bedroom
apartment. High quality video-phone (intercom) system, electric immersion
heater and two-way light switches in the bedrooms. In the kitchen all fitted
appliances will be wired inside the walls by a spur fused unit and will include
points for oven, microwave, kitchen hob, washing machine, dishwasher,
refrigerator and extractor fan.
Elevator
Installation of two 8-person elevator with an alarm system in case of
emergency. Private elevators for the apartments 001 and 004.
Metal
works
Themal aluminium windows and doors with double-glazing of the choice of the
Architect. Aluminium Venetian blinds of external use for the bedroom windows
and doors. Metal balustrades to staircases. Metal glass railing on the
verandas.
Wood
works
Internal doors, wardrobes and bathroom benches with laminated boards. Kitchen
benches and wall units with MDF lacquered finish. Entrance door of the
apartment to be ½ hour fire – resistant with timber veneer finish. The bench
tops will be of techno-granite.
General
Letter boxes will be installed at the entrance hall of the building, one for
each apartment. Central television system will be installed on the roof.
